Magnetic Stirrer – DLMS503 features magnetic agitation for laboratory liquid mixing and solution preparation. Its 12 L maximum mixing capacity supports solution mixing, and the RT+5°C to 200°C solution control temperature range provides temperature control during stirring. The LCD screen displays temperature, rotation speed, and countdown timer parameters on one interface, allowing users to monitor and control mixing settings during operation. Read More
| Max. Mixing Capacity | 12 L |
|---|---|
| Speed Range | 200–1600 rpm (2000 rpm optional) |
| Platform Material | Aluminum Alloy |
| Platform Size | 180 × 180 mm |
| Solution Control Temperature | RT+5–200°C |
| Control Temperature Accuracy | ±0.3°C |
| Heating Power | 650 W |
| Input Power | 750 W |
| Temperature Deviation Protection | Stops heating when measured temperature exceeds the set temperature by a specified value of 0–30°C |
| Extreme Over-Temperature Protection | Stops heating when the platform temperature exceeds the set temperature |
| Anti-Hot Warning Light | Flashes when platform temperature exceeds 55°C |
| Display | LCD Screen |
| Overall Dimensions (W × D × H) | 210 × 330 × 130 mm |
| Net Weight | 5 kg |
• LCD screen displays temperature, rotation speed, and countdown timer parameters on one interface.
• Microcomputer speed control maintains stirring speed under changing liquid viscosity.
• Aluminum alloy platform provides a smooth surface with thermal and corrosion resistance.
• High output torque supports mixing liquids with different viscosities and capacities.
• Corrosion-resistant guide groove helps prevent spilled liquid from reaching electronic components.
• Temperature deviation protection stops heating when the measured temperature exceeds the set temperature by the specified value.
• Anti-hot warning light flashes when the platform temperature exceeds 55°C to indicate a hot surface.
• Anti-Hot Cover
